Oil-Lubricated PM VSD Screw Air Compressor
| Model 模型 | |||||
| Oil-Lubricated PM VSD Screw Air Compressor 油润滑 PM VSD 螺杆式空气压缩机 |
|||||
| Model 模型 | Air Flow / Working Pressure(m³/min / MPa) 空气流量/工作压力（立方米/分钟/兆帕） |
Power(kW) 功率（千瓦） | Noise LeveldB(A) 噪声水平（dB(A)） | Dimensions (LWH)(cm) 尺寸（长宽高）（厘米） | Weight(kg) 重量（公斤） |
| 10A | 1.1/0.8 | 7.5 | 66±2 dB 66±2 分贝 | 75*60*80 | 110 |
| 0.95/1.0 | |||||
| 0.8/1.25 | |||||
| 20A | 2.3/0.8 | 15 | 68±2 dB 68±2 分贝 | 105*75*106 | 210 |
| 2.0/1.0 | |||||
| 1.7/1.25 | |||||
| 30A | 3.6/0.8 | 22 | 69±2 dB 69±2 分贝 | 117*80*118 | 275 |
| 3.2/1.0 | |||||
| 2.9/1.25 | |||||
| 50A | 6.3/0.8 | 37 | 70±2 dB 70±2 分贝 | 143*75*110 | 420 |
| 5.7/1.0 | |||||
| 5.1/1.25 | |||||
| 60A | 7.7/0.8 | 45 | 72±2 dB 72±2 分贝 | 156*96*130 | 435 |
| 7.0/1.0 | |||||
| 5.8/1.25 | |||||
| 75A | 9.2/0.8 | 55 | 73±2 dB 73±2 分贝 | 187*115*151 | 700 |
| 8.7/1.0 | |||||
| 7.5/1.25 | |||||
| 100A | 13.3/0.8 | 75 | 75±2 dB 75±2 分贝 | 196*120*150 | 900 |
| 11.6/1.0 | |||||
| 9.8/1.25 | |||||
| Power (kW) 功率（千瓦） | Noise dB(A) | Dimensions (cm) | Weight (kg) | ||
| 10A | 1.1/0.8 | 7.5 | 66+2 | 132*50*106 | 150 |
| 0.95/1.0 | |||||
| 0.8/1.25 | |||||
| 15A | 1.5/0.8 | 11 | 68+2 | 150*50*107 | 155 |
| 1.4/1.0 | |||||
| 1.2/1.25 | |||||
| 20A | 2.3/0.8 | 15 | 68+2 | 160*80*110 | 160 |
| 2.0/1.0 | |||||
| 1.7/1.25 | |||||
| 30A | 3.6/0.8 | 22 | 69+2 | 160*80*120 | 180 |
| 3.2/1.0 | |||||
| 2.9/1.25 | |||||
| 40A | 5.0/0.8 | 30 | 69+2 | 170*80*120 | — |
| 4.3/1.0 | |||||
| 3.7/1.25 | |||||
| 50A | 6.3/0.8 | 37 | 70+2 | 170*90*120 | — |
| 5.7/1.0 | |||||
| 5.1/1.25 | |||||
Q: How to choose air compressor?
问：如何选择空气压缩机？
问：如何选择空气压缩机？
A: When selecting an air compressor, it’s important to consider the specific needs of your site. Factors to consider include the required flow rate, desired pressure, whether an oil-based or oil-free machine is preferred, and the dew point temperature of the compressed air. By taking these factors into account, you can choose an air compressor that meets your specific needs and ensures optimal performance.
答：选择空气压缩机时，务必考虑您所在场所的具体需求。需要考虑的因素包括所需流量、期望压力、是否需要油基或无油机型，以及压缩空气的露点温度。综合考虑这些因素，您可以选择一款满足您特定需求并确保最佳性能的空气压缩机。
答：选择空气压缩机时，务必考虑您所在场所的具体需求。需要考虑的因素包括所需流量、期望压力、是否需要油基或无油机型，以及压缩空气的露点温度。综合考虑这些因素，您可以选择一款满足您特定需求并确保最佳性能的空气压缩机。
Q: Which payment terms you can accept?
问：你们接受哪些付款方式？
问：你们接受哪些付款方式？
A: We can accept flexible payment include Bank Transfer, LC, DP, or Combination terms as negotiation.
答：我们可以接受灵活的付款方式，包括银行转账、信用证、付款交单或多种付款方式的组合，具体可协商。
答：我们可以接受灵活的付款方式，包括银行转账、信用证、付款交单或多种付款方式的组合，具体可协商。
Q: Which shipping way can you provide?
问：你们提供哪些运输方式？
问：你们提供哪些运输方式？
A: We can provide shipping by sea, by air , by express and etc according to customer requirements.
答：我们可以根据客户要求提供海运、空运、快递等运输方式。
答：我们可以根据客户要求提供海运、空运、快递等运输方式。
Q: Can you do OEM and ODM?
问：你们可以做 OEM 和 ODM 吗？
问：你们可以做 OEM 和 ODM 吗？
A: Yes, OEM and ODM are both available for us. With the requirements customization of the material, colors, style, the basic quantities will be advised after we discussed together.
答：是的，我们提供 OEM 和 ODM 服务。我们会根据您的需求定制材料、颜色、款式等，并在共同商讨后确定基本订购数量。
答：是的，我们提供 OEM 和 ODM 服务。我们会根据您的需求定制材料、颜色、款式等，并在共同商讨后确定基本订购数量。
Q: How to place order?
问：如何下单？
问：如何下单？
A: When you are ready to order, please contact us for confirm the suitable solution & plan & model. What cannot be ignored is you should provide a copy purchase order to ensure that your order is processed properly.
答：当您准备下单时，请联系我们确认合适的解决方案、方案和型号。请务必提供采购订单副本，以确保您的订单能够得到妥善处理。
答：当您准备下单时，请联系我们确认合适的解决方案、方案和型号。请务必提供采购订单副本，以确保您的订单能够得到妥善处理。
Q: What is the MOQ?
问：最小起订量是多少？
问：最小起订量是多少？
A: The MOQ, or minimum order quantity, for sample orders is just 1 set. However, for compressors ranging from 7.5-37kw, the minimum quantity is 3-5 sets. For compressors over 55KW, the MOQ is 1-2 sets. It’s important to note that the MOQ can be adjusted based on your specific situation, so be sure to discuss your needs with our team.
答：样品订单的最小起订量（MOQ）仅为 1 台。但是，对于功率在 7.5-37 千瓦之间的压缩机，最小起订量为 3-5 台。对于功率超过 55 千瓦的压缩机，最小起订量为 1-2 台。需要注意的是，最小起订量可以根据您的具体情况进行调整，因此请务必与我们的团队沟通您的需求。
答：样品订单的最小起订量（MOQ）仅为 1 台。但是，对于功率在 7.5-37 千瓦之间的压缩机，最小起订量为 3-5 台。对于功率超过 55 千瓦的压缩机，最小起订量为 1-2 台。需要注意的是，最小起订量可以根据您的具体情况进行调整，因此请务必与我们的团队沟通您的需求。
Q: How long will you take to arrange production?
问：你们需要多长时间才能安排生产？
问：你们需要多长时间才能安排生产？
A: As an experienced air compressor manufacturer, our standard production time is typically between 20-25 days.
答：作为一家经验丰富的空气压缩机制造商，我们的标准生产周期通常为 20-25 天。
答：作为一家经验丰富的空气压缩机制造商，我们的标准生产周期通常为 20-25 天。
Q: How about your after-sales service?
问：你们的售后服务如何？
问：你们的售后服务如何？
A: 1. Provide customers with installation and commissioning online instructions.
A：1. 向客户提供在线安装和调试说明。
A：1. 向客户提供在线安装和调试说明。
2. Prepare and Well-trained engineers available to overseas service within one year.
2. 准备并训练有素的工程师，以便在一年内提供海外服务。
2. 准备并训练有素的工程师，以便在一年内提供海外服务。
3. Worldwide agents and after service available.
3. 提供全球代理商和售后服务。
3. 提供全球代理商和售后服务。
Senovair boasts a 15,000 ㎡ production base equipped with a specialized testing validation workshop, ensuring stable performance and energy efficiency of every air compressor before delivery.We have also built a full-process production line for air tanks, allowing us to provide a more complete and integrated product portfolio. We are committed to supplying customers with highly competitive products and tailored compressed air system solutions.
Senovair employs a professional technical team that leads industry innovation.Backed by a complete pre-sales and after-sales service team offering product consultation and reliable technical support,we are dedicated to bringing high-quality air compressors to the global market and advancing green, sustainable development across the industry.
